Square D VH364DSGL

Square D VH364DSGL

$5,100.00 USD
$6,794.00 USD $5,100.00 USD
Sale Sold out
Shipping calculated at checkout.
  • Manufacturer: Square D
  • Model: VH364DSGL
  • Model Location: Florida

Seller Info:

Seller Profile Page:

  • Verified Seller
  • Hassle-Free Transaction
  • Fast Shipping

Product Single Throw Safety Switch

Duty Rating Heavy duty

Device Application Heavy application

Disconnect Type Fusible disconnect

Factory Installed Neutral Field installed kit available

Number of Poles 3

Current Rating 200 A

Voltage Rating 600 V AC/DC

Enclosure Rating NEMA 4X stainless steel 304

Standard Motor Power Rating 50 hp at 480 V AC 50-60 Hz for 3 phase motors

125 hp at 480 V AC 50-60 Hz for 3 phase motors

60 hp at 600 V AC 50-60 Hz for 3 phase motors

150 hp at 600 V AC 50-60 Hz for 3 phase motors

40 hp at 250 V DC

50 hp at 600 V DC

Complementary

Short-circuit current 10 kA for H, K, J or R without fuse rejection clips

200 kA for R with fuse rejection clips

200 kA for J

Fuse type H or K

R or J

Mounting Type Surface

Electrical Connection Lugs

Wiring configuration 3-wire

Wire Size AWG 6...250 kcmil copper or aluminium

Tightening torque 275 lbf.in (31.07 N.m) 0.02…0.2 in² (13.3…127 mm²) (AWG 6...250 kcmil)

Depth 8.937 in (227.000 mm)

Width 17.474 in (443.840 mm)

Height 28.9 in (734.06 mm)

Net Weight 56.99 lb(US) (25.85 kg)

Grounding Kit Factory installation

Service Entrance Suitable service entrance for USA

Suitable service entrance for Mexico



Condition: New
